Video Surveillance GPS Tracking
Real time video display
Embedded Linux operating system

  • 1 composite video input, 1 composite video output
  • 1 channel audio input, 1 channel audio output
  • Standard PAL format, 25 frame/sec & NTSC. 30 frame/sec
  • Image compression H.264, variable rate (VBR)/fixed stream (CBR)
  • Optional CIF/D1 image format
  • Monitor the quality of PAL: 720x576 (D1) NTSC: 720x480 (D1)
  • Playback quality of PAL: 352x288 (CIF) NTSC: 352x480 (CIF)
  • Audio bit rate 16KB/S
  • Dual Domain name design
  • Built in SD storage (1G - 64G)
  • Basic GPS tracking w/OTA functions
  • Voltage 9V – 30V
  • 2 digital inputs, 2 outputs
  • Fleet management standard report
  • Built in 3D tilt sensor (crash report, harsh brake/acceleration reports)
  • Built in backup battery (LI-ION 1050mAH) Standby 3 days
  • Built in GSM/GPS antenna
  • Built in buzzer for over speed warning
  • Low battery report
  • Smart speed report
  • Towed report
  • Geo-Fence: 5 Circular, 5 Rectangular, 20 points
  • SOS Button
  • Customized com port available

Optional Accessories:
OBD50 (OBDII data module)
CAN50 (Canbus data module)
FU700 (Vehicle fuel tank converter)
FN100 (Truck fuel tank needle)
ID200 (Driver ID detection)
RL100 (Starter kill relay 12V or 24V)
MDT (HS100 or HS200) or Garmin navigation (FMI protocol)
Camera (CVBS) for Digital Video Recorder

Additional wireless receiver & wireless sensor:
AX01-12C (Wireless receiver)
TM700F (Wireless temperature sensor)
DT700F (Wireless door sensor)
T56AH (Wireless panic button)

Available module Range:
CV1000CG CDMA 2000 EVDO (3G)
